ATEM Camera Control Panel

Remotely control four cameras, all from a single control panel!

The ATEM Camera Control Panel is a professionally built broadcast camera control unit that extends the software features in ATEM Software Control to add high quality physical buttons and controls that are much faster to use. ATEM Constellation supports camera control when used with the Blackmagic Studio Cameras, URSA Mini Pro and URSA Broadcast cameras for full remote camera control. The control panel lets a single person monitor and adjust a wide range of camera parameters such as black levels, gain, color balance, shutter speed and more. This leaves your camera operators free to focus on more important tasks such as framing and shot composition. Plus it works with all ATEM switcher models!

Find Reseller
Works with Blackmagic Studio, URSA Mini and Broadcast Cameras

Works with Blackmagic Studio, URSA Mini and Broadcast Cameras

ATEM Constellation works with the latest Blackmagic SDI cameras that have studio camera features that you can remotely control! This means you get remote camera control, tally indicators and a DaVinci color corrector built in. All control is via the switcher aux output connection to the camera PGM SDI input, allowing you to broadcast control commands from the switcher to the camera with a single SDI cable! That means you can remotely control settings in the camera plus focus, iris and zoom on supported lenses. Pocket Cinema Cameras include a DaVinci primary color corrector so you get more than simple CCU controls as you can also do a full color grade in the camera for a cinematic look!

Control Blackmagic Cameras

Control Blackmagic Pocket Cinema Cameras

One person can control up to 4 cameras at the same time!

When working on live production, it’s important all of the cameras are matched with proper color balance so that you get a consistent look as you cut and transition between the different cameras. The ATEM Camera Control Panel features 4 camera controllers in one panel, so you can simultaneously control 4 of your cameras at the same time. When used with a larger number of cameras, you can control more even on a single panel because it's very quick to change which camera you control on each CCU channel. Each camera controller includes a LCD screen with soft buttons and knobs and a full set of traditional CCU controls, so you always get a clear indication of the camera state.

Scene and Camera Controls

Scene and Camera Controls

The top section on each camera control has settings for changing camera settings, plus it lets you save and recall scene presets. Getting remote access to important camera settings is vital when you are working in conditions where the light can change during your job such as daylight, and with these settings you can quickly adjust cameras based on changes in the scene. Controls in this section include master gain, white balance, shutter speed and more!

White Balance
White Balance

Quickly get the perfect white balance by triggering the camera’s automatic white balance feature.

Load Scenes
Load Scenes

Save and recall scene presets, perfect when you do regular work with the same conditions each day.

Master Gain
Master Gain

Boost sensitivity of the sensor as conditions become darker or when more depth of field is needed.

Shutter Speed
Shutter Speed

Set the shutter speed of the camera and a slower shutter speed can also boost brightness in dark conditions.

Color Bars
Color Bars

Select to output color bars for the selected camera. Color bars are very useful when setting up for a new job!

Scene and Camera Controls

Gain and Pedestal Controls

The center section features independent RGB controls for adjusting the camera color for the white and black parts of the image. Because the Blackmagic cameras with studio features have a full DaVinci Resolve primary color corrector built in, you have amazing control over the color in the camera. These red, green and blue controls for adjusting blacks and whites mean you can accurately match multiple cameras, which is vital for cutting seamlessly without color shifts. One trick experienced camera control operators use is to only adjust the red and blue channels, so you can add and remove red and blue tint without getting to far away from accurate color!

White Balance
White Balance

Independent RGB controls for adjusting the white part of the image.

Black Balance
Black Balance

Independent RGB controls for adjusting the black part of the image.

Lens and Iris Controls

Lens and Iris Controls

The lower section of the panel is where the most used controls are located and features a large easy to read camera number that highlights red when the camera is on air! The main control for operating the cameras is the high quality professional joystick that’s used to precisely adjust the iris when moved up and down, and the master black when the knob is rotated. This is the exact same type of control that's used on camera control units used in broadcast, so you get a true professional user interface that can be the ideal training tool for any high end live broadcast truck or studio. There's also a button to lock the CCU and indicators for network and errors.

Iris Control
Iris Control

Joystick for adjusting iris and master black. Move up/down for iris, rotate for black and push for monitoring.

Coarse Control
Coarse Control

To stop the iris from becoming too sensitive with different lens types, you can reduce the adjustment range.

Lock Controls
Lock Controls

To ensure you don't accidentally bump the camera adjustment, you can lock the iris and master black control.

Master Black
Master Black

This indicator provides feedback on the amount of master black adjustment applied to the remote camera.

Panel Active
Panel Active

If you have setup a perfect color match between all of your cameras, then you can lock all panel adjustments.

Status Lights
Status Lights

On ATEM Constellation, these lights indicate status of network and SMPTE fiber camera connections.

Preview
Preview

Used for switching the camera feed to an aux video output, so you don’t have to push the joystick.

Camera Number
Camera Number

Big camera number display shows you what camera is assigned to each channel and turns red when on air!

Call Button
Call Button

Flashes tally light on the camera to get the attention of the camera operator that you need to talk to them.

Expand Your Production Workflow

Expand Your Production Workflow

Works seamlessly with all ATEM control panels!

Adding the ATEM Camera Control Panel to your ATEM Constellation is easy as all the network settings have been assigned for you, so you can simply connect an Ethernet cable direct from the ATEM Camera Control Panel to the switchers Ethernet connection. The ATEM panels feature loop through Ethernet connections so you just loop through the panels. Because Ethernet is a network, you can interconnect multiple ATEM Camera Control Panels with the ATEM Advanced Panels to complete a customized and professional broadcast production studio. Plus, if you're doing location work, you can move the panels between any ATEM switcher model for different types of jobs.

True Broadcast Camera Control

True Broadcast Camera Control

ATEM Constellation is the tiny switcher that’s big on features!

Even though ATEM Constellation is a compact 2 rack unit design, it doesn't mean it’s small on the inside! ATEM Constellation is a massive switcher and adding ATEM hardware panels gives you the exact same professional workflow that’s used by broadcasters worldwide. If you're doing paid work, need a professional system for education or just want the speed of a hardware panel then the ATEM Camera Control Panel is well worth the investment. The ATEM Camera Control is incredibly fast to use as it features traditional CCU controls so you get the benefit of years of broadcast experience. Now even startup companies and education can use a true professional broadcast switcher.
